Beschreibung

Velleman s DPDT On-On switch model TS-5E is a robust solution for electronic applications. With its PCB-mount design, it is ideal for projects that require reliable switching. It features high quality workmanship and long service life.

The Velleman TS-5E switch is commonly used in electronic projects where dual switching functionality is required. Thanks to its DPDT (Double Pole Double Throw) type design, it allows two circuits to be switched simultaneously, which is useful in more complex circuits. It can be used in audio equipment, control systems and other applications requiring precise switching.

– Switching position: 2-3, 5-6: On; 2-1, 5-4: On
– Board type: PCB
– Contact power: 3A at 120 V AC or 28 V DC
– Contact resistance: max. 20 ohms
– Dielectric strength: 1000 V
– Insulation resistance: min. 1000Mohm
– Electrical life: 60000 cycles
– Operating temperature range: -30 °C to +85 °C
– Materials: diallil phthalate housing, brass lever handle, chrome-plated, silver-plated contacts

– DPDT On-On PCB Switch TS-5E

– DPDT switch
– PCB mounting
– High quality workmanship
– Long life
– Compact design
– Color: silver
